The POLARFLEX is a flexible, continuous, insulated hot water pipe system with integrated frost-protection strip.
Operating temperature: -22 to +68 °F
Operating pressure: PN 16
Dimensions: DN 20–100
Carrier pipe: PE 100
Insulation: Polyurethane (PUR)
Application: Cold and waste water pipes that cannot be laid at a depth that is safe from frost.
| Type | Min. bending radius | Max. ring length* | |
| Jumbo | Maxi | ||
| m | m | m | |
| CPE 25/76 | 0.70 | 520 | 780 |
| CPE 32/76 | 0.80 | 520 | 780 |
| CPE 40/91 | 0.80 | 370 | 570 |
| CPE 50/91 | 0.90 | 370 | 570 |
| CPE 63/126 | 1.00 | 192 | 305 |
| CPE 75/126 | 1.00 | 192 | 305 |
| CPE 90/162 | 1.20 | 92 | 150 |
| CPE 110/162 | 1.20 | 92 | 150 |
